How to use Yanhua Mini ACDP RF Adapter Remote Frequency Tester

YANHUA ACDP RF Adapter can be used alone as well.

How to use Yanhua Mini ACDP RF Adapter Remote Frequency Tester



Yanhua RF Adapter with Mini ACDP to test key frequency
Source:
http://www.obdexpress.co.uk/wholesale/acdp-rf-adater-remote-frequency-tester.html

Yanhua Mini ACDP BMW CAS Tester FAQ

Yanhua Mini ACDP BMW CAS tester function FAQ:
1: Is the CAS program running normally?A:The indicator light D2 flickers to indicate that the tester CAN bus communicates with the CAS module normally.

2: Is the CAS data valid?A:The indicator light D4 is long on, indicating that the CAS module data is valid.

3: Does the key have an inductive signal output?A:The key is placed in the induction coil, and the D3 indicator flickers, indicating that the key has an LF signal output.

4: Is the key legal and valid?A:The tester beeps, indicating that the key is successfully validated for the valid key of the corresponding CAS module or the newly assigned key.

5:Where to get it?How much?
A:It sales on obdexpress.co.uk,€72.99 with shipping free,Entrance:http://www.obdexpress.co.uk/wholesale/yanhua-mini-acdp-bmw-cas-tester.html

Yanhua Mini ACDP BMW CAS Tester:

Video demo:

How to use Yanhua Mini ACDP BMW CAS Tester For CAS3 module:

How to use Yanhua Mini ACDP BMW CAS Tester For CAS4 module

Source:http://www.obdexpress.co.uk/wholesale/yanhua-mini-acdp-bmw-cas-tester.html

How to use Mini ACDP for 2010-2018 Porsche BCM

Tested successfully! Yanhua Mini ACDP is able to make new keys to Porsche 2010-2018.

Tool: Yanhua Mini ACDP + Module 10

Time: around 8 minutes

Step-by-step instruction:

Run Mini ACDP Porsche software

ACDP starts to add new keys to Porsche...

Add new key for new Porsche - ICP IMMO - MC9S12XEP100 (Mask 1N35H) - Add key (auto mode)

Note:

- Pls prepare OBP+ICP adapter, BCM interface board, BCM module, BAV adapter and blank key

- It is forbidden to cut ACDP power off during the process of adding a key

- Pls store the original and programmed EEPROM/DFLASH data as prompts.

Note:

- Pls connect ACDP device, OBP+ICP adapter, BCM interface board, BCM module

- Check the crystal oscillator package of BCM module: EXT1 short - circuited for ceramic packaged crystal oscillator, EXT2 short-circuited for metal packaged crystal oscillator

- Save the chip data read by the BCM module according to the software tips

Pin detection status:

When EXT contact is bad, check the EXT1 pin if the crystal oscillator is ceramic packaged or EXT2 pin if it’s metal packaged

It’s detected that the BCM module chip has been encrypted. Continue

Read PFLASH, EEPROM/DFLASH data and save data

Immo information:

Pls make sure the info is correct

Note:

- Keep the ACDP device power on

Disconnect the OBP+ICP adapter and ACDP device firstly. (Keep the OBD+ICP adapter, BCM interface board and BCM module connected)

- Connect the ACDP device to the BAV-KEY adapter and put the key correctly in the BAV-KEY adapter

ACDP read out the current key ID

Select a number for adding a key

(the gray number is not optional, that mean this key number is already used or current key is already exit)

Mini ACDP is rogramming key...

Store DFLASH data

Note:

- Keep the ACDP device power on

Disconnect the OBP+ICP adapter and ACDP device firstly.

- Connect the ACDP device, OBD+ICP adapter, BCM interface board and BCM module

- Check the crystal oscillator package of BCM module: EXT1 short - circuited for ceramic packaged crystal oscillator, EXT2 short-circuited for metal packaged crystal oscillator

Pin detection status

It’s detected that the BCM module chip has been encrypted

Check the key information

Adding key completed

Pls install the BCM module back to the vehicle to confirm that the new key can be used normalyy

Success
